TECHNICAL SPECIFICATION
--------------------------------------------------------------------------------------------------
Engine
Type Air cooled, 4 - stroke single cylinder OHC
Displacement 149.2 cc
Max. Power 10.6 kW (14.4 PO@ 8500 rpm)
Max. Torque 12.80 N m @ 6500 rpm
Bore x Stroke 57.3 x 57.8 mm
Carburettor CV type with carburetor controlled variable ignition
Starting Self Start
Ingnition AMI - Advanced Microprocessor Ignition Sy
Transmission & Chassis
Cluch Multiplate wet
Gear box 5 Speed constant mesh
Chassis Type Tabular, diamond type
Suspension
Front Telescopic hydraulic type
Rear Rectuglar swing arm with 5 step adjustab gas reservior suspension
Brakes
Front Brake Disc Dia 240 mm
Rear Brake Disc Disc Dia 220 mm
Rear Brake Drum Drum internal expanding shoe type (130 mm)
Wheels & Tyres
Rim Size Front 18 x 1.85, 5 Spoke cast wheel
Rim Size Rear 18 x 2.15, 5 Spoke cast wheel
Tyre Size Front 80 / 100 x 18 - 47 P
Tyre Size Rear 100 / 90 x 18 - 56 P
Electricals
Battery 12 V -4 Ah, MF battery
Head Light 12 V -35 WI 35W - Halogen bulb - Trapeze
Tail Stop Lamp 12 V -0.5 WI 4.1W (LED lamps - Clear lens)
Turn Signal Lamp 12 V -21 W (Amber bulb) x 4 nos. (MFR - CI)
Dimensions
Length 2080mm
Width 765mm
Height 1145mm
Wheelbase 1325 mm
Ground Clearance 145 mm
Fuel Tank Capacity 12.1 litre (Min)
Reserve 1.5 litre (Usable reserve)
Kerb Weight 148 kg (Brakes - FR/ RR --> Disc/ Drum)
Features
> New digital - Analog combo meter console > All secure ignition switch with key shutter
> Diamond lustre headlight > Anti drag fuel tank
> 5 spoke wheels & front and rear disc brakes. > Prism shell LED tail lamp
New digital – Analog combo meter console
