TECHNICAL SPECIFICATION
--------------------------------------------------------------------------------------------------

Engine

Type                  Air cooled, 4 - stroke single cylinder OHC, fuel injection
Displacement 223 cc
Max. Power 13.15 kW (17.6 bhp) @ 7000rpm
Max. Torque 18.35 N m @ 6000 rpm
Acceleration 0-60 kmph in 3.7 sec
Bore x Stroke 65.5 x 66.2 mm
Compression Ratio 9.0 : 1

Starting Self Start

Ingnition DC - FTIS (Full Transistorised Ignition System)
Engine oil grade SAE 10 W 30 SJ grade (JASO MA Grade)

Transmission & Chassis
Cluch                 Multi-plate wet
Gear box 5 Speed constant mesh
Chassis Type Diamond Frame

Suspension

Front Telescopic hydraulic shock absorbers
Rear Swing arm with 5 step adjustable IGRS system

Brakes
Front Brake Disc, Dia 276 mm
Rear Brake Disc Disc Dia 240 mm
Wheels & Tyres
Rim Size Front 18 x 1.85, 5 Spoke cast wheel
Rim Size Rear 18 x 2.15, 5 Spoke cast wheel
Tyre Size Front 80 / 100 x 18 - 47 P tubeless
Tyre Size Rear 100 / 90 x 18 - 56 P tubeless

Electricals

Battery                  12 V -6 Ah, MF - Wet battery
Head Light 12 V -35 W / 35W - Halogen bulb (Multi - reflector D.C type)
Position Lamp 12 V - 5 W X 2 nos.
Tail Stop Lamp 12 V -0.5 W / 4.1W LED lamp
Turn Signal Lamp 12 V -21 W (Amber bulb) x 4 nos. (Multi - reflector clear
lens)

Dimensions

Length                   2110 mm
Width                   805 mm
Height                   1175 mm
Wheelbase 1350 mm
Ground Clearance 159 mm
Kerb Weight                 159 kgs
Minimum Turning 2.50 metre
Features

> Astra gold front and rear disc plates.
> Aerodynamic design for superior handling at high speeds.
> Multi - Functional digital console with blue iIIumination and personalised message.
> Sporty full body cowl with body-coloured rear-view mirrors.
> Excellent visibility and less prone to damage.
> High intensite integrated LED tail light with integrated clear lens indicators.
Karizma ZMR
