Phoenix

TECHNICAL SPECIFICATION

--------------------------------------------------------------------------------------------------

Engine

Type Air-cooled, 4-stroke single cylinder, OHC

Displacement 97.2 cc

Max. Power 5.5 Kw (7.5 Ps) at 8000 rpm

Max. Torque 7.95 Nm at 5000 rpm

Transmission & Chassis

Cluch Multi-plate wet

Gear box 4 Speed constant mesh

Chassis Type Tubular double cradle frame

Suspension

Front Telescopic hydraulic shock absorbers

Rear Swing arm with hydraulic shock absorber

Brakes

Front Brake Internal expanding shoe type (130 mm) type

Rear Brake Disc Internal expanding shoe type (130 mm) type

Wheels & Tyres

Rim Size Front 18 x 1.60, Alloy /spoke wheel

Rim Size Rear 18 x 1.60, Alloy / spoke wheel

Tyre Size Front 2.75 x 18 - 42 P / 4 PR

Tyre Size Rear 2.75 x 18 - 48 P / 6 PR

Electricals

Battery 12V-2.5 Ah

Head Light 35W / 35W - Halogen bulb ( Multi - reflector type )

Dimensions

Length 1970 mm

Width 720 mm

Height 1040 mm

Wheelbase 1230 mm

Saddle Height 785 mm

Ground Clearance 7.95 159mm

Fuel Tank Capacity 11 ltrs ( Min)

Reserve 1 ltrs ( Usable reserve )

Kerb Weight 109 kg
