Phoenix

TECHNICAL SPECIFICATION

--------------------------------------------------------------------------------------------------

Engine

Type Air cooled, 4-stroke single cylinder OHC

Displacement 124.7 CC

Max. Power 6.72 KW (9BHP) @ 7000 RPM

Max. Torque 10.35 N-m @ 4000 RPM

Bore x Stroke 52.4 x 57.8 mm

Compression Ratio 9.1 : 1

Starting Self start / Kick start

Ingnition AMI -Advanced Microprocessor Ignition System

Engine oil grade SAE 10 W 30 SJ grade

Transmission & Chassis

Cluch Multiplate wet

Gear box 4 Speed constant mesh

Chassis Type Tubular double cradle type

Suspension

Front Telescopic hydraulic shock absorbers

Rear Swing arm with hydraulic shock absorber

Brakes

Front Brake 240 mm Dia: Pad - Non asbestos type

Rear Brake Drum Internal expanding shoe type (130 mm) Liners - Non asbestos type

Wheels & Tyres

Rim Size Front 18 x 1.60, Spoke wheel / Cast wheel

Rim Size Rear 18 x 1.60, Spoke wheel / Cast wheel

Tyre Size Front 2.75 x 18 - 42 P/ 4 PR

Tyre Size Rear 3.00 x 18 - 52 P / 6 PR

Electricals

Battery 12V-3 Ah, MF battery

Head Light 12V-35W/35W-Halogen bulb (Multi - reflector tyre)

Tail Stop Lamp 12V-5 / 21 W (Multi - reflector)

Turn Signal Lamp 12V-10W (Amber bulb) x 4 nos (MFR - Clear lens)

Dimensions

Length 2005 mm

Width 735 mm

Height 1070 mm

Wheelbase 1265 mm

Ground Clearance 150 mm

Fuel Tank Capacity 13.6 Ltrs (Min)

Kerb Weight 125 Kg (Kick) / 129 Kg (Self)
